6.1. Mounting storage

Mounting storage as disks and filesystems

There are multiple ways of mounting a disk to a virtual machine. In this section we will mount various disks to our VM.

Kubernetes storage

There are multiple methods to provide storage for your virtual machines. For storage to be attached you have to specify a volume in the spec.templates.spec.volumes block of your virtual machine. This volume must then be referenced as a device in spec.templates.spec.domain.devices.disks or spec.templates.spec.domain.devices.filesystems.

A sample configuration of a PersistentVolumeClaim mounted as a disk:

apiVersion: kubevirt.io/v1
kind: VirtualMachine
metadata:
  name: my-vm
spec:
  template:
    spec:
      domain:
        devices:
          disks:
            - name: harddisk
              disk: {}
      [...]
      volumes:
        - name: harddisk
          persistentVolumeClaim:
            claimName: harddisk-pvc

The following types are the most important volume types which KubeVirt supports:

cloudInitNoCloud: Attach a cloud-init data source. Requires a proper setup of cloud-init.
cloudInitConfigDrive: Attach a cloud-init data source. Similar to cloudInitNoCloud, this requires a proper setup of cloud-init. The config drive can be used for Ignition.
persistentVolumeClaim: Provide persistent storage using a PersistentVolumeClaim.
dataVolume: Simplifies the process for creating virtual machine disks. Without using DataVolumes the creation of a PersistentVolumeClaim is on behalf of the user.
ephemeral: Local copy-on-write image where the original data is never mutated. KubeVirt stores writes in an ephemeral image on local storage.
containerDisk: Disk images are pulled and backed by a local store on the node.
emptyDisk: Attach an empty disk to the virtual machine. An empty disk survives a guest restart but not a virtual machine recreation.
hostDisk: Allows to attach a disk residing somewhere on the local node.
configMap: Allows to mount a ConfigMap as a disk or a filesystem.
secret: Allows to mount a Secret as a disk or a filesystem.
serviceAccount: Allows to mount a ServiceAccount as a disk or a filesystem.
downwardMetrics: Expose a limited set of VM and host metrics in a vhostmd compatible format to the guest.

You can find more information about the configuration options of volumes in the Volume API reference . You can find volume examples in the KubeVirt storage documentation .

KubeVirt disks

Besides other options, a disk referenced in the spec.templates.spec.domain.devices section can be:

lun: The disk is attached as a LUN device allowing to execute iSCSI command passthrough
disk: Expose the volume as a regular disk
cdrom: Expose the volume as a cdrom drive (read-only by defaul)
fileystems: Expose the volume as a filesystem to the VM using virtiofs

Sample configuration:

apiVersion: kubevirt.io/v1
kind: VirtualMachine
metadata:
  name: my-vm
spec:
  template:
    spec:
      domain:
        devices:
          filesystems:
            - name: myconfigmap
              virtiofs: {}
          disks:
            - name: harddisk
              disk:
                bus: virtio
            - name: lundisk
              lun:
                reservation: true
            - name: cdrom
              cdrom:
                writable: false
                bus: sata
      [...]
      volumes:
        - name: harddisk
          persistentVolumeClaim:
            claimName: harddisk-pvc
        - name: lundisk
          persistentVolumeClaim:
            claimName: lun-pvc
        - name: cdrom
          persistentVolumeClaim:
            claimName: cdrom-pvc

You can find more information about the configuration options of disks in the Disk API reference . You can find disk examples in the KubeVirt storage documentation .

Note

In contrast to disks, a filesystem reflects changes in the source to the volume inside the VM. However, it is important to know that a volume mounted as a filesystem does not allow live migration.

PersistentVolumeClaims as block or filesystem devices

It might be a bit confusing as the name filesystem is overloaded. In this section we are talking about the storage mode of a PersistentVolumeClaim and not the mounting inside our guest. Kubernetes supports the volumeMode type block and filesystem (default). Whether you can use block devices or not depends on your CSI driver supporting block volumes.

Filesystem: A volume is mounted into pods into a directory. If the volume is backed by a block device and the device is empty, Kubernetes creates a filesystem on the device before mounting it for the first time.
Block: Specifies that the volume is a raw block device. Such volume is presented in a pod as a block device without any filesystem on it. This mode is useful to provide a pod with the fastest possible way to access a volume, without any filesystem layer between the pod and the volume.

When creating a DataVolume we can specify whether the disk should be of type Filesystem or Block. Requesting a blank volume will look like this:

apiVersion: cdi.kubevirt.io/v1beta1
kind: DataVolume
metadata:
  name: lab06-block-disk
spec:
  source:
    blank: {}
  storage:
    volumeMode: Block
    accessModes:
      - ReadWriteOnce
    resources:
      requests:
        storage: 128Mi

This specification translate to the PersistentVolumeClaim as follows:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: lab06-block-disk
  [...]
spec:
  accessModes:
  - ReadWriteOnce
  resources:
    requests:
      storage: "134217728"
  volumeMode: Block
  [...]

We can clearly see that the volumeMode Block is requested.

Mounting storage

Let us create some storage and mount it to a virtual machine using different options.

Note

Attached storage must be mounted in the virtual machine. The most convenient option is to use a system initialization tool like cloud-init.

Task 6.1.1: Prepare and create disks and configmaps

First, we create a disk using the default Filesystem volume mode. Create the file dv_lab06-fs-disk.yaml in the folder labs/lab06 with the following content:

apiVersion: cdi.kubevirt.io/v1beta1
kind: DataVolume
metadata:
  name: lab06-fs-disk
spec:
  source:
    blank: {}
  storage:
    volumeMode: Filesystem
    accessModes:
      - ReadWriteOnce
    resources:
      requests:
        storage: 128Mi

Create the filesystem-backed disk in the Kubernetes cluster:

kubectl apply -f labs/lab06/dv_lab06-fs-disk.yaml --namespace lab-<username>

Then we create a disk using the Block volume mode. Create the file dv_lab06-block-disk.yaml in the folder labs/lab06 with the following content:

apiVersion: cdi.kubevirt.io/v1beta1
kind: DataVolume
metadata:
  name: lab06-block-disk
spec:
  source:
    blank: {}
  storage:
    volumeMode: Block
    accessModes:
      - ReadWriteOnce
    resources:
      requests:
        storage: 128Mi

Create the block storage disk in the Kubernetes cluster:

kubectl apply -f labs/lab06/dv_lab06-block-disk.yaml --namespace lab-<username>

Next, we create a cloud-init configuration secret. Create a file cloudinit-userdata.yaml in the folder labs/lab06 with the following content:

#cloud-config
password: kubevirt
chpasswd: { expire: False }
timezone: Europe/Zurich

Create the secret in the Kubernetes cluster:

kubectl create secret generic lab06-cloudinit --from-file=userdata=labs/lab06/cloudinit-userdata.yaml --namespace lab-<username>

Last but not least, we create a ConfigMap with some values for an application. Create a file cm_lab06-application.yaml in the folder labs/lab06 with the following content:

kind: ConfigMap
apiVersion: v1
metadata:
  name: lab06-application
data:
  singlevalue: hello
  application.properties: |
    my.property=true
    another.property=42

Create the ConfigMap in the Kubernetes cluster:

kubectl apply -f labs/lab06/cm_lab06-application.yaml --namespace lab-<username>

Task 6.1.2: Create a virtual machine mounting the storage

We create a virtual machine mounting the following storage:

Initialization using cloud-init
- Create mount points for disks, secrets, serviceaccounts and configmaps.
- Format pvc disks
Filesystem backed disk to /disks/fs
Block backed disk to /disks/block
Secret to /secrets/cloudinit
ServiceAccount to /serviceaccounts/default
ConfigMap to /configmaps/application

The VirtualMachine manifest for this looks like the following snippet. Create a file vm_lab06-storage.yaml in the folder labs/lab06 with the following content:

apiVersion: kubevirt.io/v1
kind: VirtualMachine
metadata:
  name: lab06-storage
spec:
  runStrategy: Halted
  template:
    metadata:
      labels:
        kubevirt.io/domain: lab06-storage
    spec:
      domain:
        devices:
          filesystems:
            - name: serviceaccount-fs
              virtiofs: {}
            - name: cloudinit-fs
              virtiofs: {}
            - name: configmap-fs
              virtiofs: {}
          disks:
            - name: containerdisk
              disk:
                bus: virtio
            - name: cloudinitdisk
              disk:
                bus: virtio
            - name: blockdisk
              disk:
                bus: virtio
            - name: fsdisk
              disk:
                bus: virtio
          interfaces:
            - name: default
              masquerade: {}
        resources:
          requests:
            memory: 2Gi
      networks:
        - name: default
          pod: {}
      volumes:
        - name: containerdisk
          containerDisk:
            image: quay.io/containerdisks/fedora:43
        - name: blockdisk
          persistentVolumeClaim:
            claimName: lab06-block-disk
        - name: fsdisk
          persistentVolumeClaim:
            claimName: lab06-fs-disk
        - name: serviceaccount-fs
          serviceAccount:
            serviceAccountName: default
        - name: cloudinit-fs
          secret:
            secretName: lab06-cloudinit
        - name: configmap-fs
          configMap:
            name: lab06-application
        - name: cloudinitdisk
          cloudInitNoCloud:
            userData: |
              #cloud-config
              password: kubevirt
              chpasswd: { expire: False }
              bootcmd:
                - sudo test -z "$(sudo blkid /dev/vdc)" && sudo mkfs -t ext4 -L blockdisk /dev/vdc
                - sudo test -z "$(sudo blkid /dev/vdd)" && sudo mkfs -t ext4 -L fsdisk /dev/vdd
                - sudo mkdir -p /disks/block
                - sudo mkdir -p /disks/fs
                - sudo mkdir -p /serviceaccounts/default
                - sudo mkdir -p /secrets/cloudinit
                - sudo mkdir -p /configmaps/application
                - sudo mount -t virtiofs serviceaccount-fs /serviceaccounts/default
                - sudo mount -t virtiofs cloudinit-fs /secrets/cloudinit
                - sudo mount -t virtiofs configmap-fs /configmaps/application
              mounts:
                - ["/dev/vdc", "/disks/block", "ext4", "defaults,nofail", "0", "2" ]
                - ["/dev/vdd", "/disks/fs", "ext4", "defaults,nofail", "0", "2" ]

Create the virtual machine:

kubectl apply -f labs/lab06/vm_lab06-storage.yaml --namespace lab-<username>

Start the virtual machine with:

virtctl start lab06-storage --namespace lab-<username>

Open a console to the virtual machine:

virtctl console lab06-storage --namespace lab-<username>

After logging in (user: fedora, passowrd: kubevirt) you can examine the virtual machine. First you may check the block device output with lsblk:

lsblk

NAME   MAJ:MIN RM  SIZE RO TYPE MOUNTPOINTS
zram0  251:0    0  1.9G  0 disk [SWAP]
vda    252:0    0    5G  0 disk
├─vda1 252:1    0    2M  0 part
├─vda2 252:2    0  100M  0 part /boot/efi
├─vda3 252:3    0 1000M  0 part /boot
└─vda4 252:4    0  3.9G  0 part /var
                                /home
                                /
vdb    252:16   0    1M  0 disk
vdc    252:32   0  252M  0 disk /disks/block
vdd    252:48   0  257M  0 disk /disks/fs

Another variant to also list the other mounts is, e.g., showing the device usage:

df -h

Filesystem         Size  Used Avail Use% Mounted on
/dev/vda4          4.0G  418M  3.1G  12% /
devtmpfs           4.0M     0  4.0M   0% /dev
tmpfs              981M     0  981M   0% /dev/shm
tmpfs              393M  780K  392M   1% /run
tmpfs              981M     0  981M   0% /tmp
/dev/vda3          966M   74M  827M   9% /boot
/dev/vda2          100M   17M   84M  17% /boot/efi
/dev/vda4          4.0G  418M  3.1G  12% /home
/dev/vda4          4.0G  418M  3.1G  12% /var
serviceaccount-fs   16G   12K   16G   1% /serviceaccounts/default
cloudinit-fs        16G  4.0K   16G   1% /secrets/cloudinit
/dev/vdc           119M   15K  110M   1% /disks/block
/dev/vdd           115M   46K  106M   1% /disks/fs
tmpfs              197M  4.0K  197M   1% /run/user/1000
configmap-fs       226G  123G   94G  57% /configmaps/application

Explore how the cloud-init secret and the configmap have been mounted in the VM by using the following commands:

ls -l /secrets/cloudinit/
cat /secrets/cloudinit/userdata

ls -l /configmaps/application/
cat /configmaps/application/singlevalue
cat /configmaps/application/application.properties

Next, try to edit the configmap within Kubernetes. You can open a new terminal in your webshell or leave the console and head back later. Issue the following command to alter the ConfigMap resource:

kubectl patch cm lab06-application --type json --patch '[{ "op": "replace", "path": "/data/singlevalue", "value": "kubevirt-training" }]' --namespace lab-<username>

After some time, the change should be seamlessly propagated to your VM. Head back to the console and check the value of your mounted configmap:

cat /configmaps/application/singlevalue

kubevirt-training

Analyze mounting behaviour

Another thing to note is how our virtual machine pods are set up. Leave the console and describe the virt-launcher pod responsible for your VM:

kubectl describe pod virt-launcher-lab06-storage-<pod> --namespace lab-<username>

Name:             virt-launcher-lab06-storage-<pod>
[...]
Containers:
  [...]
  compute:
    [...]
    Mounts:
      /var/run/kubevirt-private/vmi-disks/fsdisk from fsdisk (rw)
      /var/run/kubevirt/virtiofs-containers from virtiofs-containers (rw)
      [...]
    Devices:
      /dev/blockdisk from blockdisk
  virtiofs-serviceaccount-fs:
    [...]
    Command:
      /usr/libexec/virtiofsd
    Args:
      --socket-path=/var/run/kubevirt/virtiofs-containers/serviceaccount-fs.sock
      --shared-dir=/var/run/secrets/kubernetes.io/serviceaccount/
      --cache=auto
      --sandbox=none
    Mounts:
      /var/run/kubevirt/virtiofs-containers from virtiofs-containers (rw)
      /var/run/secrets/kubernetes.io/serviceaccount from kube-api-access-mmf6t (ro)
  virtiofs-cloudinit-fs:
    [...]
    Mounts:
      /var/run/kubevirt-private/secret/cloudinit-fs from cloudinit-fs (rw)
      /var/run/kubevirt/virtiofs-containers from virtiofs-containers (rw)
      [...]
  virtiofs-configmap-fs:
    [...]
    Mounts:
      /var/run/kubevirt-private/config-map/configmap-fs from configmap-fs (rw)
      /var/run/kubevirt/virtiofs-containers from virtiofs-containers (rw)
      [...]
Volumes:
  [...]
  cloudinit-fs:
    Type:        Secret (a volume populated by a Secret)
    SecretName:  lab06-cloudinit
  configmap-fs:
    Type:      ConfigMap (a volume populated by a ConfigMap)
    Name:      lab06-application
  blockdisk:
    Type:       PersistentVolumeClaim (a reference to a PersistentVolumeClaim in the same namespace)
    ClaimName:  lab06-block-disk
  fsdisk:
    Type:       PersistentVolumeClaim (a reference to a PersistentVolumeClaim in the same namespace)
    ClaimName:  lab06-fs-disk
  virtiofs-containers:
    Type:       EmptyDir (a temporary directory that shares a pod's lifetime)
  kube-api-access-mmf6t:
    Type:                    Projected (a volume that contains injected data from multiple sources)

Above output is shortened quite significantly and shows the pod description’s relevant sections. Our virt-launcher pod has multiple helper containers managing the mounts. Every storage is shown in the volumes block. The ServiceAccount is actually in the kube-api-access volume. The compute container is the container running our virtual machine where our storage should be available.

Disk Mounts: Block storage and filesystem storage

Our two PersistentVolumeClaims - one backed by a filesystem and one being a raw block device - are mounted differently.

fsdisk: Is in the mount block of the compute container.
blockdisk: Does not show up in the mount block of the compute container. However, we see the blockdisk as /dev/blockdisk in the devices section in the compute container. This means that our block storage is indeed passed as a device.

Filesystem mounts: Virtiofs volumes

Our Secret, ConfigMap and ServiceAccount are mounted to the guest as filesystem. They are using the shared filesystem Virtiofs . For each mounted filesystem there is a supporting container virtiofs-<volume>. In our case the supporting containers are virtiofs-serviceaccount-fs, virtiofs-cloudinit-fs, virtiofs-configmap-fs.

Let’s analyze the virtiofs-serviceaccount-fs and compute container.

Containers:
  compute:
    [...]
    Mounts:
      /var/run/kubevirt/virtiofs-containers from virtiofs-containers (rw)
      [...]
  virtiofs-serviceaccount-fs:
    [...]
    Command:
      /usr/libexec/virtiofsd
    Args:
      --socket-path=/var/run/kubevirt/virtiofs-containers/serviceaccount-fs.sock
      --shared-dir=/var/run/secrets/kubernetes.io/serviceaccount/
      --cache=auto
      --sandbox=none
    Mounts:
      /var/run/kubevirt/virtiofs-containers from virtiofs-containers (rw)
      /var/run/secrets/kubernetes.io/serviceaccount from kube-api-access-mmf6t (ro)

The container is running the virtiofsd file system daemon (see command)
The virtiofsd has access to the underlying data (in our case ServiceAccount) as it mounts the data (see mounts in virtiofs-serviceaccount-fs)
The virtiofsd is creating/using the socket /var/run/kubevirt/virtiofs-containers/serviceaccount-fs.sock
This socket is on the virtiofs-containers volume (see args and mount in virtiofs-serviceaccount-fs)
This volume is also mounted by the compute container (see the mount section in compute)

This establishes a communication channel using sockets. This channel is used by QEMU from the compute container to communicate with virtiofsd in virtiofs-serviceaccount-fs.

Virtiofs Design

Stop your VM

As we are at the end of this section it is time to stop your running virtual machine with:

virtctl stop lab06-storage --namespace lab-<username>
